# 回滚 Deployment

返回 Deployment

某些情况下,您可能想要回滚(rollback)Deployment,例如:Deployment 不稳定(可能是不断地崩溃)。默认情况下,kubernetes 将保存 Deployment 的所有更新(rollout)历史。您可以设定 revision history limit 来确定保存的历史版本数量。

TIP

当且仅当 Deployment 的 .spec.template 字段被修改时(例如,您修改了容器的镜像),kubernetes 将为其创建一个 Deployment revision(版本)。Deployment 的其他更新(例如:修改 .spec.replicas 字段)将不会创建新的 Deployment reviesion(版本)。

模拟更新错误

  • 假设您在更新 Deployment 的时候,犯了一个拼写错误,将 nginx:1.9.1 写成了 nginx:1.91

    kubectl set image deployment.v1.apps/nginx-deployment nginx=nginx:1.91 --record=true

    1

    输出结果如下所示:

    deployment.apps/nginx-deployment image updated

    1
  • 该更新将卡住,您可以执行命令 kubectl rollout status deployment.v1.apps/nginx-deployment 检查其状态,输出结果如下所示:

    Waiting for rollout to finish: 1 out of 3 new replicas have been updated...

    1
  • 执行命令 kubectl get rs 您将看到两个旧的 ReplicaSet(nginx-deployment-1564180365 and nginx-deployment-2035384211)和一个新的 ReplicaSet (nginx-deployment-3066724191) 。如下所示:

    NAME                          DESIRED   CURRENT   READY   AGE
    nginx-deployment-1564180365   3         3         3       25s
    nginx-deployment-2035384211   0         0         0       36s
    nginx-deployment-3066724191   1         1         0       6s

    1
    2
    3
    4
  • 执行命令 kubectl get pods,您将看到 1 个由新 ReplicaSet 创建的 Pod 卡在抓取 image 的死循环里:

    NAME                                READY     STATUS             RESTARTS   AGE
    nginx-deployment-1564180365-70iae   1/1       Running            0          25s
    nginx-deployment-1564180365-jbqqo   1/1       Running            0          25s
    nginx-deployment-1564180365-hysrc   1/1       Running            0          25s
    nginx-deployment-3066724191-08mng   0/1       ImagePullBackOff   0          6s

    1
    2
    3
    4
    5

    TIP

    Deployment Controller 将自动停止有问题的更新(rollout),不会继续 scale up 新的 ReplicaSet。maxUnavailable 参数指定了最多会有几个 Pod 副本卡住,该参数的默认值是 25%。

  • 执行命令 kubectl describe deployment 查看 Deployment 的详情,输出结果如下所示:

    Name:           nginx-deployment
    Namespace:      default
    CreationTimestamp:  Tue, 15 Mar 2016 14:48:04 -0700
    Labels:         app=nginx
    Selector:       app=nginx
    Replicas:       3 desired | 1 updated | 4 total | 3 available | 1 unavailable
    StrategyType:       RollingUpdate
    MinReadySeconds:    0
    RollingUpdateStrategy:  25% max unavailable, 25% max surge
    Pod Template:
      Labels:  app=nginx
      Containers:
      nginx:
        Image:        nginx:1.91
        Port:         80/TCP
        Host Port:    0/TCP
        Environment:  <none>
        Mounts:       <none>
      Volumes:        <none>
    Conditions:
      Type           Status  Reason
      ----           ------  ------
      Available      True    MinimumReplicasAvailable
      Progressing    True    ReplicaSetUpdated
    OldReplicaSets:     nginx-deployment-1564180365 (3/3 replicas created)
    NewReplicaSet:      nginx-deployment-3066724191 (1/1 replicas created)
    Events:
      FirstSeen LastSeen    Count   From                    SubobjectPath   Type        Reason              Message
      --------- --------    -----   ----                    -------------   --------    ------              -------
      1m        1m          1       {deployment-controller }                Normal      ScalingReplicaSet   Scaled up replica set nginx-deployment-2035384211 to 3
      22s       22s         1       {deployment-controller }                Normal      ScalingReplicaSet   Scaled up replica set nginx-deployment-1564180365 to 1
      22s       22s         1       {deployment-controller }                Normal      ScalingReplicaSet   Scaled down replica set nginx-deployment-2035384211 to 2
      22s       22s         1       {deployment-controller }                Normal      ScalingReplicaSet   Scaled up replica set nginx-deployment-1564180365 to 2
      21s       21s         1       {deployment-controller }                Normal      ScalingReplicaSet   Scaled down replica set nginx-deployment-2035384211 to 1
      21s       21s         1       {deployment-controller }                Normal      ScalingReplicaSet   Scaled up replica set nginx-deployment-1564180365 to 3
      13s       13s         1       {deployment-controller }                Normal      ScalingReplicaSet   Scaled down replica set nginx-deployment-2035384211 to 0
      13s       13s         1       {deployment-controller }                Normal      ScalingReplicaSet   Scaled up replica set nginx-deployment-3066724191 to 1

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    20
    21
    22
    23
    24
    25
    26
    27
    28
    29
    30
    31
    32
    33
    34
    35
    36
    37

    为了修复这个问题,您需要将其回滚到之前的一个稳定版本。

检查 Deployment 的更新历史

  1. 执行命令 kubectl rollout history deployment.v1.apps/nginx-deployment 检查 Deployment 的历史版本,输出结果如下所示:

    deployments "nginx-deployment"
    REVISION    CHANGE-CAUSE
    1           kubectl apply --filename=https://k8s.io/examples/controllers/nginx-deployment.yaml --record=true
    2           kubectl set image deployment.v1.apps/nginx-deployment nginx=nginx:1.9.1 --record=true
    3           kubectl set image deployment.v1.apps/nginx-deployment nginx=nginx:1.91 --record=true

    1
    2
    3
    4
    5

    CHANGE-CAUSE 是该 revision(版本)创建时从 Deployment 的 annotation kubernetes.io/change-cause 拷贝而来。

    您可以通过如下方式制定 CHANGE-CAUSE 信息:

    • 为 Deployment 增加注解,kubectl annotate deployment.v1.apps/nginx-deployment kubernetes.io/change-cause="image updated to 1.9.1"
    • 执行 kubectl apply 命令时,增加 --record 选项
    • 手动编辑 Deployment 的 .metadata.annotation 信息
  2. 执行命令 kubectl rollout history deployment.v1.apps/nginx-deployment --revision=2,查看 revision(版本)的详细信息,输出结果如下所示:

    deployments "nginx-deployment" revision 2
      Labels:       app=nginx
              pod-template-hash=1159050644
      Annotations:  kubernetes.io/change-cause=kubectl set image deployment.v1.apps/nginx-deployment nginx=nginx:1.9.1 --record=true
      Containers:
      nginx:
        Image:      nginx:1.9.1
        Port:       80/TCP
        QoS Tier:
            cpu:      BestEffort
            memory:   BestEffort
        Environment Variables:      <none>
      No volumes.

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13

回滚到前一个 revision(版本)

下面的步骤可将 Deployment 从当前版本回滚到前一个版本(version 2)

  1. 执行命令 kubectl rollout undo deployment.v1.apps/nginx-deployment 将当前版本回滚到前一个版本,输出结果如下所示:

    deployment.apps/nginx-deployment

    1

    或者,您也可以使用 --to-revision 选项回滚到前面的某一个指定版本,执行如下命令:

    kubectl rollout undo deployment.v1.apps/nginx-deployment --to-revision=2

    1

    输出结果如下:

    deployment.apps/nginx-deployment

    1

    更详细的信息,请参考 kubectl rollout

    此时,Deployment 已经被回滚到前一个稳定版本。您可以看到 Deployment Controller 为该 Deployment 产生了 DeploymentRollback event。

  2. 执行命令 kubectl get deployment nginx-deployment,检查该回滚是否成功,Deployment 是否按预期的运行,输出结果如下:

    NAME               DESIRED   CURRENT   UP-TO-DATE   AVAILABLE   AGE
    nginx-deployment   3         3         3            3           30m

    1
    2
  3. 执行命令 kubectl describe deployment nginx-deployment 查看 Deployment 的详情,输出结果如下:

    Name:                   nginx-deployment
    Namespace:              default
    CreationTimestamp:      Sun, 02 Sep 2018 18:17:55 -0500
    Labels:                 app=nginx
    Annotations:            deployment.kubernetes.io/revision=4
                            kubernetes.io/change-cause=kubectl set image deployment.v1.apps/nginx-deployment nginx=nginx:1.9.1 --record=true
    Selector:               app=nginx
    Replicas:               3 desired | 3 updated | 3 total | 3 available | 0 unavailable
    StrategyType:           RollingUpdate
    MinReadySeconds:        0
    RollingUpdateStrategy:  25% max unavailable, 25% max surge
    Pod Template:
      Labels:  app=nginx
      Containers:
      nginx:
        Image:        nginx:1.9.1
        Port:         80/TCP
        Host Port:    0/TCP
        Environment:  <none>
        Mounts:       <none>
      Volumes:        <none>
    Conditions:
      Type           Status  Reason
      ----           ------  ------
      Available      True    MinimumReplicasAvailable
      Progressing    True    NewReplicaSetAvailable
    OldReplicaSets:  <none>
    NewReplicaSet:   nginx-deployment-c4747d96c (3/3 replicas created)
    Events:
      Type    Reason              Age   From                   Message
      ----    ------              ----  ----                   -------
      Normal  ScalingReplicaSet   12m   deployment-controller  Scaled up replica set nginx-deployment-75675f5897 to 3
      Normal  ScalingReplicaSet   11m   deployment-controller  Scaled up replica set nginx-deployment-c4747d96c to 1
      Normal  ScalingReplicaSet   11m   deployment-controller  Scaled down replica set nginx-deployment-75675f5897 to 2
      Normal  ScalingReplicaSet   11m   deployment-controller  Scaled up replica set nginx-deployment-c4747d96c to 2
      Normal  ScalingReplicaSet   11m   deployment-controller  Scaled down replica set nginx-deployment-75675f5897 to 1
      Normal  ScalingReplicaSet   11m   deployment-controller  Scaled up replica set nginx-deployment-c4747d96c to 3
      Normal  ScalingReplicaSet   11m   deployment-controller  Scaled down replica set nginx-deployment-75675f5897 to 0
      Normal  ScalingReplicaSet   11m   deployment-controller  Scaled up replica set nginx-deployment-595696685f to 1
      Normal  DeploymentRollback  15s   deployment-controller  Rolled back deployment "nginx-deployment" to revision 2
      Normal  ScalingReplicaSet   15s   deployment-controller  Scaled down replica set nginx-deployment-595696685f to 0

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    20
    21
    22
    23
    24
    25
    26
    27
    28
    29
    30
    31
    32
    33
    34
    35
    36
    37
    38
    39
    40
    41
